TesterKit

TesterKit Documentation #

TesterKit is a Python-native hardware test platform for the AI-assisted era.

Documentation Sections #

SectionDescription
TutorialEngineer's First Project - progressive learning path
How-To GuidesStep-by-step guides for common tasks
ConceptsParts, stations, capabilities, fixtures, and matching
ReferenceMCP tools, HTTP endpoints, CLI, models
IntegrationAdopt TesterKit with existing tests and infrastructure
ExamplesTwelve runnable example projects: a seven-rung adoption ladder (01-vanilla → 07-profiles), plus five standalone topical examples (08-waveform-evidence → 12-parallel-sites)

Quick Start #

Run an example:

cd examples/01-vanilla && uv run pytest -v

Start the UI:

testerkit serve

Configure for Claude Code: (Anthropic's terminal AI coding assistant)

testerkit setup claude-code

Architecture Overview #

flowchart TB
    subgraph User["User Layer"]
        direction LR
        pytest["pytest tests"]
        cli["CLI"]
        ui["UI (NiceGUI)"]
        mcp["MCP Server"]
    end

    subgraph Platform["Platform Layer"]
        direction LR
        cfg["Config Loader"]
        drv["Instrument Drivers"]
        match["Matching Service"]
        part["Part Specs"]
        station["Station Configs"]
        data["Data Backend"]
    end

    subgraph Storage["Storage Layer"]
        direction LR
        events["Events<br/>(Arrow IPC + DuckDB)"]
        channels["Channels<br/>(time-series)"]
        files["Files<br/>(artifacts)"]
        parquet["Runs<br/>(Parquet)"]
    end

    pytest --> Platform
    cli --> Platform
    ui --> Platform
    mcp --> Platform
    Platform --> Storage

Key Features #

  • pytest integration — Use familiar pytest patterns with hardware
  • Config-driven — YAML configuration, Pydantic validation
  • Capability matching — Automatically match parts to compatible stations
  • Simulated mode — Develop without hardware
  • AI-ready — MCP server for Claude Code, Cursor, Cline
  • Event log — Typed event stream with Arrow IPC storage and DuckDB queries
  • Channel store — Time-series instrument data with LTTB decimation
  • Parquet storage — Efficient columnar storage for analytics
  • Live monitoring — Real-time event subscriptions via Arrow Flight

Learning Paths #

New to TesterKit? #

Start with the Tutorial — a progressive learning path from your first test to production deployment.

Have Existing Tests? #

Check out Integration — guides for adopting TesterKit incrementally with LabVIEW, TestStand, or existing pytest suites.

Quick Reference #

Jump to Reference for API documentation, configuration schemas, and CLI commands.

Project Structure #

testerkit/
├── models/          # Pydantic models for every YAML entity (project, station, part, capability, ...)
├── store.py         # Canonical YAML I/O — every read/write of catalog / station / part / fixture YAML
├── instruments/     # Instrument base classes (Instrument, VisaInstrument) + Mock factory
├── matching/        # Capability matching service
├── pytest_plugin/   # pytest plugin (fixtures, markers, sidecar loader)
├── execution/       # Test-execution helpers (verify, harness, logger, decorators)
├── data/            # Parquet schema + backend, event log/store, run store, channel store
├── mcp/             # MCP server (12 `testerkit_*` tools)
├── api/             # HTTP API (FastAPI)
├── ui/              # Operator UI (NiceGUI)
└── client.py        # Python client library

Getting Help #
